99.999% Unpolished Optical Sapphire Infrared Optical Materials
  • name
  • name

99.999% Unpolished Optical Sapphire Infrared Optical Materials

MOQ: 10 pcs
Delivery Period: 1-4 weeks
Payment Method: T/T,Western Union,
Supply Capacity: 100000 pcs/Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
jingjing
Certification
ISO9001
Material:
Optical Grade Sapphire
Orientation:
C-axis
Purity:
99.999%
Hardness:
Mohs 9.0
Diameter:
1-500mm
Diameter Tolerance:
+0.05mm
Thickness:
0.1-100mm
Thickness Tolerance:
+0.05mm
Surface:
Fine Grinding
Roughness:
1.0μm
Minimum Order Quantity:
10 pcs
Delivery Time:
1-4 weeks
Payment Terms:
T/T,Western Union,
Supply Ability:
100000 pcs/Month
Highlight:

99.999% Unpolished Optical Sapphire

,

Unpolished Infrared Optical Materials

,

Sapphire Infrared Optical Materials

Product Description

High Purity 99.999% Sapphire Single Crystal Blanks Optical Crystal Infrared Material

Sapphire is a single crystal aluminum oxide (Al2O3),is renowned for its exceptional optical properties and wide range of applications in various industries. Sapphire's remarkable attributes, such as high hardness, excellent optical transparency, chemical stability, and thermal conductivity, make it an ideal material for optical components in demanding environments.



99.999% Unpolished Optical Sapphire Infrared Optical Materials 0



Properties of Single Crystal Sapphire:

Chemical formula Al₂O₃
Purity 99.999%
Crystal structure Hexagonal
Hardness Mohs 9.0
Fusion point 2045℃
Boiling point 2980℃
Coefficient of Thermal Expansion 5.8x10 -6/K
Specific heat 0.418W.s/g/k
Thermal conduction 25.12W/m/k(@100°C)
Refractive index no=1.768 ne=1.760
dn/dt 13×10-6/K(@633nm)
Transmission T≈80%(0.3-5μm)
Permittivity 11.5(//c), 9.3(⊥c)





99.999% Unpolished Optical Sapphire Infrared Optical Materials 199.999% Unpolished Optical Sapphire Infrared Optical Materials 2

99.999% Unpolished Optical Sapphire Infrared Optical Materials 3



Sapphire Optical glass blanks

Jingjing Technology (Hubei) Co., Ltd can supply high quality fine grinding sapphire optical glass blanks.

We can cut the material into the shape as requirements, such as square shape, round shape, spherical shape and so on.

If have any query, please contact with us.
