Custom Optical Sapphire Glass Window Hardness 9.0 Protective Window
  • name
  • name
  • name

Custom Optical Sapphire Glass Window Hardness 9.0 Protective Window

MOQ: 10 pcs
Delivery Period: 1-4 weeks
Payment Method: T/T,Western Union,
Supply Capacity: 100000 pcs/Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Jingjing
Certification
ISO9001
Operating Temperature:
-55℃-100℃
Parallelism:
≤3 ARC Min
Ttransmittance:
99% At 635nm After Coating
Diamter:
0.1-500mm
Tolerance:
±0.03mm
Thickness:
0.1-100mm
Thickness Tolerance:
±0.03mm
Material:
Optical Sapphire
Surface Quality:
DSP 40/20
Chamfer:
0.1-0.3mm*45°
Clear Aperture:
90%
Surface Accuracy:
λ/6
Use:
Optical
Minimum Order Quantity:
10 pcs
Delivery Time:
1-4 weeks
Payment Terms:
T/T,Western Union,
Supply Ability:
100000 pcs/Month
Highlight:

Custom Optical Sapphire Glass

,

Sapphire Glass Window Hardness 9.0

,

Hardness 9.0 Protective Window

Product Description

Custom Optical Sapphire Glass Windows Protective Window Hardness 9.0

Why choose Sapphire?

Sapphire is composed of alumina, and its crystal structure is hexagonal lattice structure.

Synthetic sapphire common application facets are A-Plane,C-Plane, and R-Plane. Due to the wide optical penetration band of sapphire, it has good light transmission from near ultraviolet (190nm) to mid-infrared. Therefore, it is widely used in optical components, infrared devices, high-intensity laser lens materials.

Sapphire also has the characteristics of high sound velocity, high temperature resistance, corrosion resistance, high hardness, high light transmittance, high melting point (2045℃), etc., so it is often used as a material for photoelectric components.

Custom Optical Sapphire Glass Window Hardness 9.0 Protective Window 0Custom Optical Sapphire Glass Window Hardness 9.0 Protective Window 1Custom Optical Sapphire Glass Window Hardness 9.0 Protective Window 2

Technical Parameters:

Product name Sapphire Optical window
Material Optical sapphire
Diameter 1-500mm
Diameter Tolerance ±0.03mm
Thickness 0.1-100m
Thickness tolerance ±0.03mm
Parallelism ≤3 ARC Min
Surface quality DSP 40/20
Chamfer 0.1-0.3mm*45°
Clear Aperture 90%



Fields of Application for the Optical Sapphire Window:

-Scanner

-Watch glasses

-Semiconductor applications (e.g. wafers)

-Cell phones (displays and display protection)

-Infrared-/ and UV-applications (e.g. sensors, monitoring systems, thermal cameras)

-Medical devices (e.g. endoscope windows, scalpels and laser surgery, light guides in dermatology)



Military applications (e.g. night vision devices and cameras, satellite and space technology, control systems)



FAQ

Q:What is your minimum order requirement?

A:MOQ: 10 pieces



Q:How long will it take to execute my order ?

A:10-25 days after confirming the payment.



Q:Can you give warranty of your products ?

A:We promise the quality, if the quality has any problems, we will produce new produces or return you money.



Q: Do you provide free samples?

A: We can provide free samples if we have stock optics as your request,but the freight is yours.



Q: What is your terms of payment ?

A:T/T, Western Union ,Paypal
