WHY ARE SAPPHIRE WINDOWS SUCH HIGH PERFORMERS?
Sapphire windows and flat stock are incredibly hard, strong and wear resistant:
A sapphire window can be exposed to extreme abradants such as sand and particulates with minimal effect on the clarity of the window. This makes sapphire windows the ideal material for a variety of applications such as: Aerospace windows, downhole and drilling vision systems, inspection windows, watch crystals and gun sights.
Sapphire windows can take pressure like no other clear material, making sapphire windows the go-to transparent material for high-pressure vessels, deep sea windows and sight glasses. Combined with the exceptional thermal and chemical performance of sapphire, a sapphire window is the ideal transparency for pressurized in-process, deep sea and equipment sensors.
Sapphire flats and wear parts are used in applications in which wear is a problem. Systems like canning machines, slide plates, V-blocks, flat bearings and pushers utilize sapphire flats and blocks to extend the lifetime of the equipment and reduce downtime.
Sapphire windows and flat stock are incredibly hard, strong and wear resistant:
A sapphire window can be exposed to extreme abradants such as sand and particulates with minimal effect on the clarity of the window. This makes sapphire windows the ideal material for a variety of applications such as: Aerospace windows, downhole and drilling vision systems, inspection windows, watch crystals and gun sights.
Sapphire windows can take pressure like no other clear material, making sapphire windows the go-to transparent material for high-pressure vessels, deep sea windows and sight glasses. Combined with the exceptional thermal and chemical performance of sapphire, a sapphire window is the ideal transparency for pressurized in-process, deep sea and equipment sensors.
Sapphire flats and wear parts are used in applications in which wear is a problem. Systems like canning machines, slide plates, V-blocks, flat bearings and pushers utilize sapphire flats and blocks to extend the lifetime of the equipment and reduce downtime.
Properties of Single Crystal Sapphire
| Chemical formula | Al₂O₃ |
| Purity | 99.999% |
| Crystal structure | Hexagonal |
| Density | 3.98g/cm³ |
| Hardness Mohs | 9 |
| Fusion point | 2045℃ |
| Boiling point | 2980℃ |
| Coefficient of Thermal Expansion | 5.8×10 -6 /K |
| Specific heat | 0.418W.s/g/k |
| Thermal conduction | 25.12W/m/k(@100°C) |
| Refractive index | no=1.768 ne=1.760 |
| dn/dt | 13×10-6/K(@633nm) |
| Transmission | T≈80%(0.3-5μm) |
| Permittivity | 11.5(//c), 9.3(⊥c) |
