Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows
  • name

Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows

MOQ: 10 pcs
Price: by case
Delivery Period: 1-5 weeks
Payment Method: T/T,, Western Union
Supply Capacity: 100000pcs/Month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Jingjing
Certification
ISO9001
Material:
Optical Sapphire
Orientation::
C-axis
Surface Quality:
60/40,40/20,20/10,10/5
Tolerance::
±0.05 Mm
Clear Aperture:
90%
Coating:
According To Customer Requirements
Diamter:
0.1-500mm
Tolerance:
±0.05mm
Thickness:
0.1-100mm
Thickness Tolerance:
±0.05mm
Parallelism:
≤3 ARC Min
Surface Quality:
80/50,60/40,40/20,20/10,10/5
Chamfer:
0.1-0.5mm*45
Surface Accuracy:
λ/6
Ttransmittance:
99% At 635nm After Coating
Use:
Optical
Minimum Order Quantity:
10 pcs
Price:
by case
Delivery Time:
1-5 weeks
Payment Terms:
T/T,, Western Union
Supply Ability:
100000pcs/Month
Highlight:

Dia 0.1mm Custom Sapphire Windows

,

Dia 500mm Custom Sapphire Windows

,

Optical Grade Sapphire Step Windows

Product Description
Optical grade Sapphire Step Windows
Sapphire Windows are manufactured from single crystal sapphire, making them ideal for demanding applications (such as laser systems) because of their extreme surface hardness, high thermal conductivity, high dielectric constant and resistance to common chemical acids and alkalis. Sapphire is the second hardest crystal next to diamonds and, because of their structural strength, sapphire windows can be made much thinner than other common dielectric windows with improved transmittance. Chemically, sapphire is single crystal aluminum oxide (Al2O3) and is useful in a transmission range from 0.2 - 5.5μm.



Features:

  • Product Name: Sapphire Optical Windows
  • Tolerance: ±0.05 mm
  • Surface: Polished
  • Application: For Plunger
  • Transmittance: 99% At 635nm After Coating
  • Flatness: λ/6 @ 632.8nm
  • High-Quality Sapphire Windows
  • High-Quality Sapphire Windows
  • High-Quality Sapphire Windows

Technical Parameters:

Surface Polished
Melting Point 2045°
Diameter Tolerance ±0.05 mm
Thickness Tolerance ±0.05 mm
Flatness λ/6 @ 632.8nm
Transmittance 99% At 635nm After Coating
Use Optical
Application For Plunger, Blade
Operating Temperature -55℃-100℃

High-Quality Sapphire Windows, High-Quality Sapphire Windows, High-Quality Sapphire Windows

Applications:

Optical Windows are flat, plane-parallel, transparent optical surfaces designed to protect sensors and other electronic
instruments from environment conditions.
Optical Window selection considerations include material transmission properties as well as scattering, strength and resistance to certain environments. Their use should not impact on magnification of a system. Optical Windows can be optically polished and incorporate an element for diffusing light source to control illumination.



AR coatings can be applied to ensure maximum transmission performance for a particular wavelength. The windows are made in a range of materials including UV Fused Silica, Quartz, IR Crystals and optical glasses. Our optical window properties include x-ray protection, non-browning to UV light and light transmission from deep ultra violet to far infrared.

Optical Windows products include wedges, substrates, discs, flats, plates, rods, protection windows, laser windows, camera windows, light guides and domes.



Our Windows are used by scientific and industrial companies across the world of medical, defence, instrumentation, laser, research and imaging.



All our Optical Windows can be supplied from a standard range stock. We also supply custom optical windows made to your specification, sizes and specific design.

Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows 0



Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows 1Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows 2Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows 3Dia 0.1mm-500mm Custom Sapphire Windows Optical Grade Sapphire Step Windows 4
